Schlemmer 3805122 hose screw connection SEM-FAST straight M25X1.5/NW22 gray

Out of stock

- Easy and quick assembly
- Made of high-quality polyamide 6
- Operating temperature from -40 to +120Â°C
- Halogen-free
- Protection class IP 65 (IP 68 * possible with O-ring)

2,71 €

Show net prices

incl. 19% VAT , plus

Currently out of stock

The Sem Fast hose fitting is characterized by its quick and easy installation. The hose is simply inserted into the closed screw connection until it stops.

Material:

Polyamide 6

Operating temperature:

from -40 to +120 Â°C
Flame protection according to FMVSS 302

External thread:

M 25 x 1.5

For corrugated hose:

NW 22

Color:

gray

Features:

Conically sealing on the corrugated hose
Thread sealing via sealing web
Corrugated hose can be rotated in the screw connection
High extraction values
Special locking technology
Halogen-free
Protection class IP 65 (IP 68* possible with O-ring)

Areas of application:

Mechanical and plant engineering
Vehicle construction
Automation technology
Shipbuilding

Assembly:

Separate the hose on a wave crest (optimal protection class for hose and screw connection)
Insert the hose into the â€œclosedâ€ screw connection with a slight twisting movement until it stops
Pull the corrugated hose slightly backwards in the screw connection (secure locking)

IP68*:

To achieve protection class IP 68, mount the O-ring in the first trough after the section of the corrugated hose on the screw side.

Technical features

Artikel-Nr.:	10000623
GTIN:	4262441553217
HAN:	3805122
Category:	Schlemmer SEM-FAST straight
Manufacturers:	Schlemmer
Material:	Polyamide
External thread:	M25
NW:	NW 22
Art:	SEM-FAST conduit fitting
Shape:	Flat
Dimensions ( Length × Width × Height ):	0,48 × 0,41 × 0,46 cm
