Heyco 2828N B 625-500 S WHITE SNAP-IN grommet for thin walls 17.9 mm Ã˜

Heyco 2828N B 625-500 S WHITE SNAP-IN grommet for thin walls 17.9 mm Ã˜

Heyco 2828N B 625-500 S WHITE SNAP-IN grommet for thin walls 17.9 mm Ã˜

Heyco 2828N B 625-500 S WHITE SNAP-IN grommet for thin walls 17.9 mm Ã˜

- For a plate thickness of max. 1.6 mm
- Good chemical resistance
- Good electrical properties
- Perfect for cables, ropes and pipes of all kinds
- With fastening teeth

0,36 €

Show net prices

incl. 19% VAT , plus

Available immediately
Delivery time: ca. 3 weeks (DE - int. shipments may differ)

Request personal offer!

These Heyco sockets have good chemical resistance and good electrical properties. They are used where the depth of the mounting hole is small. They provide valid electrical and mechanical protection for cables, ropes and pipes.

Thanks to the mounting teeth, these bushings lock into place and adapt to the thickness of the frame up to a specified in the table Maximum value.

Features:

Ã˜ A mm: 12.7
Ã˜ B mm: 17.9
Ã˜ G mm: 15.9
H total height (mm): 6.4
Colour: white
Mounting hole Ã˜ mm: 15.9
S mm: 0.5 - 1.6
Shape type: for thin wall thickness
Max. Plate thickness mm: 0.5 - 1.6
Temperature range: max +105Â°C
Flammability class: flame retardant and self-extinguishing UL94-V2.
Certification: UR and CSA

Technical features

Artikel-Nr.:	10231192
HAN:	2828N
Manufacturers:	HEYCO
Material:	Polyamide
Color:	White
Outer diameter in mm:	17,9
Maximum inside diameter in mm:	12,7
Mounting hole diameter in mm:	15,9
Shipping weight:	0,10 kg
Item weight:	0,00 kg
