H05VV-F 5G0.75mmÂ² PVC hose line white

H05VV-F 5G0.75mmÂ² PVC hose line white

H05VV-F 5G0.75mmÂ² PVC hose line white

H05VV-F 5G0.75mmÂ² PVC hose line white

H05VV-F 5G0.75mmÂ² PVC hose line white

Sold by the meter

1,45 €

Show net prices

incl. 19% VAT , plus

Available immediately
Delivery time: 10 - 11 Workdays (DE - int. shipments may differ)

Request personal offer!

Super flexible H05VV-F connection cable
Ã¶LFLEXÂ® SF - H05VV-F harmonized PVC connection cable. Super flexible and color-coded for versatile applications, especially as a handheld device cable
Benefits
High acceptance in Europe through harmonization
Areas of application
Particularly suitable for household appliances, power tools, DIY machines
Type H05VV-F cables may not be used in commercially used rooms, with the exception of offices.
Not for permanent outdoor use.
Product features
Flame-retardant according to IEC 60332-1-2
Highly flexible / flexible at low temperatures
Structure and geometry according to harmonization document
Ozone resistant according to EN 50396

Standard references / approvals
H05VV-F according to EN 50525-2-11, from 6 cores based on EN 50525-2-11
Construction
Super-fine stranded wire made of bare copper wires, individual wire diameter 0.07 mm
PVC core insulation, flexible at low temperatures
PVC jacket, flexible at low temperatures
orange (similar to RAL 2003)
Core identification code
Colored according to VDE 0293-308
From 6 cores: black with white numbers
Temperature range
Moves: -15Â°C to +60Â°C

Technical features

Artikel-Nr.:	10236712
HAN:	10236712
Manufacturers:	Kalitec
Cable cross-section:	0,75 mm²
Color:	White
Cores:	5
Including protective conductor (G):	Ja
Shielded:	No
Base material of the outer jacket:	Polyvinyl chloride (PVC)
Item weight:	0,09 kg
Content:	1,00 m
