Heyco 13833 TRG 1375-1250 grommet with plug 43.2 mm Ã˜

Heyco 13833 TRG 1375-1250 grommet with plug 43.2 mm Ã˜

Heyco 13833 TRG 1375-1250 grommet with plug 43.2 mm Ã˜

Heyco 13833 TRG 1375-1250 grommet with plug 43.2 mm Ã˜

- Transforms rough-edged holes into smooth, insulated holes
- Snaps securely
- Insulates and protects mechanical cables, pipes and much more.
- UL approval for applications up to 50Â°C
- Made of high qualitythermoplastic rubber

0,12 €

Show net prices

incl. 19% VAT , plus

Available immediately
Delivery time: ca. 3 weeks (DE - int. shipments may differ)

Request personal offer!

These high-quality Heyco grommets are used to transform the sharp or irregular edges of the holes into smooth and insulated. Thanks to the cutouts on the sides, they sit perfectly in place.

Features:

Ã˜ A mm: 32
Ã˜ B mm: 43.2
Ã˜ G mm: 34.9
H total height (mm): 9.1
Color: black
Mounting hole Ã˜ mm: 34.9
S mm: 0.8 - 3.2
Shape Type:-
Max. Plate thickness mm: 3.2
Temperature range: max +50Â°C
Flammability class: UL94-HB flame retardant
Certification: UR

Technical features

Artikel-Nr.:	10231274
HAN:	13833
Category:	push-in bushings
Manufacturers:	HEYCO
Material:	Thermoplastic Elastomeric
Color:	Black
Outer diameter in mm:	43,2
Mounting hole diameter in mm:	34,9
